SYN5302a-Z, V277 automatic synchronizer

SYN5302a-Z, V277 automatic synchronizer

Product Details Introduction

ABB's SYCHROTACT 5 series automatic synchronizer model SYN5302a-Z, V277 (product number: 3BHB006716R0277) is a high-precision device designed specifically for safe grid connection operations between generators and power grids or busbars in power systems. This device ensures synchronous operation under safe and reliable conditions by accurately measuring and comparing the frequency, phase, and voltage of different power sources.

Main functions and features:

Accurate measurement: Real time monitoring of the frequency, phase, and voltage of the power supply to ensure synchronization accuracy.

Automatic control: Automatically execute the grid connection process, reduce human intervention, and improve safety.

Multiple protection: It has protection functions such as overvoltage, undervoltage, overclocking, and underflocking to ensure the safety of equipment and systems.

Flexible application: Suitable for different types of generators and power system configurations, with strong adaptability.

Technical parameters:

model: SYN5302a-Z,V277

Product Code: 3BHB006716R0277

Series: SYCHROTACT 5

Input: Multiple voltage and frequency inputs

Output: synchronization signal, control signal, alarm signal

Protection Function: Overvoltage, Undervoltage, Overfrequency, Underfrequency Protection

Application areas:

Power plant: used for parallel generator and synchronous grid operation.

Distribution system: Implement parallel connection and load transfer of the power system.

Industrial application: Suitable for synchronous and backup power switching in industrial power grids.

Product imag
