Product Details Introduction

GE's IS420UCSBH1A is the UCSB controller module in the Mark VIe control system, designed specifically for executing control logic for specific applications. Unlike traditional controllers, UCSB controllers do not directly host application I/O, but communicate with I/O modules through the IONet network to ensure that application input data is not lost even during controller maintenance or repair.

Main features:

Independent computing capability: As an independent computer, the UCSB controller comes pre installed with specific application software that can run cascade or block logic.

Real time synchronization: Using the IEEE 1588 protocol, the clocks of I/O components and controllers are synchronized to within 100 microseconds through R, S, and T IONet, ensuring high-precision synchronization of the system.

Modular design: The controller adopts an air-cooled design, eliminating the need for onboard fans or batteries, and has a built-in power supply, simplifying the system architecture.

Technical specifications:

Processor: Freescale MPC7534 or Intel EP80579 may be used.

Memory: 256 MB DDR2 SDRAM with error correction code (ECC); 2 GB NAND flash memory.

Network interface: Supports IONet and Ethernet connections.

Power requirement: 18-36V DC.

Working temperature range:- 40 ° C to+85 ° C.

Size: 150mm x 100mm x 50mm.

Weight: Approximately 500g.

Product imag
