Product Details Introduction

The NI PCI4451 data acquisition card is a high-performance data acquisition device produced by National Instruments, widely used in fields such as scientific research, industrial control, automation testing, and signal processing. This data acquisition card has multiple analog input/output, digital input/output, and timing functions, which can meet the needs of various complex application scenarios.

Main functional features:

High precision analog input:

PCI4451 provides high-precision analog input and supports multi-channel acquisition. It can process multiple signals simultaneously to meet high-precision measurement requirements.

Supports up to 16 bit resolution, capable of capturing small signal changes, suitable for precision measurement.

Flexible input and output channels:

Provide multiple analog input channels (such as analog voltage input), supporting different input ranges and sampling rates.

Supports simultaneous acquisition of multiple analog signals, with input types including differential input and single ended input.

High performance timing and triggering functions:

Built in timing and triggering mechanism, which can set parameters such as sampling frequency and triggering conditions according to requirements to ensure precise time control.

Support multiple triggering modes to meet the needs of different application scenarios, such as hard triggering, software triggering, etc.

High speed data transmission:

Adopting PCI interface, providing high-speed data transmission capability, ensuring real-time signal acquisition and processing.

The high bandwidth transmission capability enables data to be quickly and accurately transmitted to the computer, ensuring real-time monitoring and processing.

Digital Input/Output:

Provide multiple digital input and output channels, suitable for switch signal acquisition and output, facilitating interaction with other digital devices.

Can be used to measure changes in switch signals or control the switch status of other devices.

Flexible driver support:

Supports multiple drivers and is compatible with software development tools provided by NI, such as LabVIEW, LabWindows/CVI, etc. It can be easily integrated into various measurement systems.

Provide NI DAQmx drivers that support multiple programming languages such as C/C++, Python, Visual Basic, etc.

Stable long-term operation:

The design emphasizes stability and is suitable for long-term high load operation, especially reliable use in industrial environments and laboratory conditions.

Compact design:

As a PCI card, it is easy to install and suitable for various standard PC workstations, saving space and improving system integration.

Product imag
