NI PXIE-5163 Oscilloscope Module

NI PXIE-5163 Oscilloscope Module

Product Details Introduction

NI PXIE-5163 is a high-performance oscilloscope module provided by National Instruments, designed specifically for the PXI (PCI eXtensions for Instrumentation) platform, mainly used in the fields of testing and measurement. This module combines high-speed sampling, rich functionality, and flexible integration options, suitable for various dynamic signal analysis and fault diagnosis applications.

Main features:

High sampling rate and resolution:

Provides a bandwidth of up to 1 GHz and a sampling rate of 5 GSa/s, suitable for measuring and analyzing high-speed signals.

With a 12 bit resolution, it can more accurately capture small signal changes.

Flexible input channels:

Equipped with multiple input channels, supporting dual channel or more configurations, making it easy to simultaneously collect multiple signals.

High precision triggering function:

Provide multiple triggering options to accurately capture the signal events of interest and adapt to different testing needs.

Scalable PXI platform:

Compatible with PXI devices, supports integration with other testing and measurement modules, and has good scalability and flexibility.

Supports software platforms such as NI LabVIEW and NI TestStand, providing rich software support suitable for automated testing and system integration.

Deep storage:

Equipped with large capacity storage, it can capture signals for a long time and is suitable for high-precision waveform capture and analysis.

Real time waveform analysis:

Support real-time waveform display and analysis, providing various waveform display modes such as FFT analysis, cycle analysis, trigger waveform, etc., to facilitate user signal analysis.

Control and operation:

Graphical operation interface: Through LabVIEW or other control software, users can achieve graphical programming, which facilitates signal acquisition, processing, and analysis.

Remote control function: Users can perform remote operations and automated testing through communication interfaces such as Ethernet or GPIB.

Application areas:

High speed signal acquisition: suitable for measuring and analyzing high-speed signals such as high-speed communication systems, RF signals, microwave frequency bands, etc.

Electronic design and development: used in the process of electronic prototype development to verify the performance of circuit design, especially in applications with high bandwidth and high sampling rate requirements.

Automated testing: suitable for signal monitoring and analysis in automated testing systems, widely used in production line testing and quality control.

Scientific research: widely used in physics, engineering, and other scientific research fields for precise dynamic signal measurement and analysis.

The NI PXIE-5163 oscilloscope module, with its high performance, high precision, and flexibility, has become an ideal choice for many high demand testing and measurement systems, especially widely used in high-speed signal acquisition and automated testing systems.

Product imag
