PM864AK01 3BSE01816R1 processor module

PM864AK01 3BSE01816R1 processor module

Product Details Introduction

PM864AK01 (part number: 3BSE01816R1) is a high-performance processor module that is a core component of ABB AC 800M control systems, widely used in industrial automation, process control, and power systems.

main features

High performance processing: adopting advanced processor architecture, supporting complex logical operations and real-time control.

Redundancy design: Supports redundancy of CPU, CEX bus, communication interfaces, and I/O modules to ensure reliable system operation.

Powerful scalability: Compatible with multiple communication protocols, supports Ethernet and serial communication, facilitating system integration.

High stability: Industrial grade design with high anti-interference ability, suitable for harsh environments.

technical specifications

model: PM864AK01

Part number: 3BSE01816R1

Storage: Supports user configurable storage capacity

Communication interface:

Ethernet: Multiple RJ45 ports (CN1, CN2)

Serial port: RS-232C（COM3、COM4）

Power requirements: External power supply, specific voltage should refer to the product manual

Built in battery: supports power-off data retention

application area

Industrial automation: used for PLC control, data acquisition, and remote monitoring

Process control: a fine control system suitable for fields such as petroleum, chemical, pharmaceutical, etc

Power system: supports substation automation, grid scheduling, and energy management

Product imag
