Horner Electric HE693ADC816 Analog Input Module

Horner Electric HE693ADC816 Analog Input Module

Product Details Introduction

Horner Electric's HE693ADC816 analog input module is a device designed specifically for industrial automation systems, providing 8 single ended analog input channels and supporting 16 bit resolution. It can convert analog input signals (such as current) into digital values and transmit the data to the PLC system, ensuring accurate data acquisition and control.

Main features:

Input range: Supports an input range of ± 1mA, suitable for various applications.

Sampling rate: Provides up to 3000 channel samples per second to ensure real-time data collection.

Input impedance: With an input impedance of 10k Ω, it ensures the accuracy of signal transmission.

Analog filtering function: Built in 1.6kHz low-pass filter to reduce signal noise.

Digital filtering function: Provides digital filtering options from 1 to 128 samples to improve data reliability.

High input voltage tolerance: capable of withstanding a maximum input voltage of 75VDC, enhancing the durability of the system.

Isolation design: Provide 500VDC backplane isolation to ensure system safety.

Common mode rejection: With a common mode rejection ratio exceeding 100dB, it ensures clear and accurate signals.

Working temperature range: suitable for working environments ranging from 0 to 60 ° C.

Application areas:

Industrial automation: Real time monitoring and control of key parameters in the production line to improve production efficiency and product quality.

Process control: Used in industries such as chemical and pharmaceutical to precisely control production processes and ensure process stability.

Energy management: Optimize energy consumption and resource allocation, and improve energy utilization efficiency.

Environmental monitoring: Collect environmental data, support data analysis and decision-making.

The HE693ADC816 module is widely used in industrial applications that require precise analog signal acquisition and processing due to its high precision, reliability, and fast sampling capability.

Product imag
