HORNER ELECTRIC HE693RTD600J Electric Input Module

HORNER ELECTRIC HE693RTD600J Electric Input Module

Product Details Introduction

HORNER ELECTRIC HE693RTD600J is a resistance temperature detection (RTD) input module used in the GE Fanuc 90-30 PLC series to achieve high-precision measurement of temperature signals. The following is the detailed information of the module:

Main features:

compatibility

Suitable for GE Fanuc 90-30 PLC, it can be directly inserted into the PLC rack and used as a temperature acquisition module.

Channel

Provide 6 input channels for RTD sensors, supporting simultaneous measurement of multiple RTD sensors.

Supported RTD types

Compatible with multiple types of RTD sensors, including:

100 Ω Platinum RTD (Pt100)

120 Ω Nickel RTD (Ni120)

10 Ω Copper RTD (Cu10)

measuring range

Pt100: -200°C ~ 850°C

Ni120: -80°C ~ 260°C

Cu10: -100°C ~ 260°C

Resolution and accuracy

Resolution: 0.1 ° C

Typical accuracy: ± 0.1% of full scale

Signal Processing and Filtering

Equipped with automatic cold end compensation to improve measurement accuracy.

Built in noise filtering function to reduce interference in industrial environments.

Communication and Data Processing

The collected temperature data can be directly accessed through the PLC logic program.

Supports analog data conversion and can be used for temperature regulation in industrial control systems.

LED indicator light

Provide input status and fault indication for easy maintenance and diagnosis.

Application areas:

Industrial Automation (Temperature Monitoring and Control)

Food processing (temperature recording and regulation)

HVAC system (heating, ventilation, air conditioning temperature control)

Chemical and metallurgical (process temperature monitoring)

Product imag
