HORNER ELECTRIC HE693KPD157 Operating Interface Module

HORNER ELECTRIC HE693KPD157 Operating Interface Module

Product Details Introduction

HORNER ELECTRIC HE693KPD157 is a Keypad Display Module used in the GE Fanuc 90-30 PLC series, providing human-machine interaction functionality that allows users to directly monitor and control the PLC's operating status on site. The following is the detailed information of the module:

Main features:

compatibility

Suitable for GE Fanuc 90-30 PLC series, directly connected to the PLC rack, used as a local HMI (Human Machine Interface).

display function

Equipped with an LCD display screen for displaying key data, alarm information, and operational status.

High contrast character display, suitable for visual operations in industrial environments.

key operation

Integrate 15 programmable buttons for data input, function selection, and system control.

Allow users to define button functions and achieve custom control and navigation.

Communication capability

Directly exchange data with PLC through I/O bus without the need for additional communication interfaces.

Low latency real-time data update, suitable for industrial control applications.

Condition monitoring

It can display the PLC operating status, I/O status, alarms, and diagnostic information for quick maintenance.

Equipped with a malfunction indicator light (LED) to indicate error or alarm status.

Installation and Configuration

Front panel installation, which can be fixed on the control cabinet or console for easy access by operators.

Configure through GE Fanuc 90-30 programming software (such as Logicmaster 90 or Proficy Machine Edition).

Application areas:

Industrial Automation (Production Line Monitoring and Control)

Process control system (adjustment of parameters such as temperature, pressure, flow rate, etc.)

Equipment maintenance and diagnosis (local data query and troubleshooting)

Manufacturing and energy industries (PLC on-site data exchange)

Product imag
