HORNER ELECTRIC HE693STP111E Stepper Motor

HORNER ELECTRIC HE693STP111E Stepper Motor

Product Details Introduction

HORNER ELECTRIC HE693STP111E is a stepper motor drive module designed for the GE Fanuc 90-30 PLC series, providing precise stepper motor control and suitable for positioning and motion control applications in automation equipment.

Main features:

compatibility

Suitable for GE Fanuc 90-30 PLC, controlling the operation of stepper motors through PLC.

Compatible with Horner Electric automation systems and can be integrated into existing industrial control architectures.

control function

Step pulse output:

Supports unipolar and bipolar stepper motors.

Can control the speed, direction, and step length of the stepper motor.

Current control:

Suitable for stepper motors of different specifications, providing adjustable current settings, optimizing power consumption and thermal management.

Communication and Data Processing

Perform motion planning and instruction execution for stepper motors through PLC programming.

High speed pulse output (PTO), supporting precise position control and acceleration/deceleration management.

Diagnostic and safety functions

LED indicator light: displays motor status, operating mode, and fault information.

Overcurrent and over temperature protection to prevent motor damage and extend equipment lifespan.

Installation and Configuration

Adopting rack mounted installation, directly inserted into GE Fanuc 90-30 PLC rack.

Configure parameter settings and motion control programming through Logicmaster 90 or Proficy Machine Edition.

Application areas:

CNC machine tools (precision positioning and feed control)

Automated production line (conveyor belt, robotic arm control)

Packaging Machinery (Precise Stepping Motion)

Semiconductor equipment (micro step high-precision control)

Product imag
