HORNER ELECTRIC HE693PBM100J Stepper Motor

HORNER ELECTRIC HE693PBM100J Stepper Motor

Product Details Introduction

HORNER ELECTRIC HE693PBM100J is a stepper motor drive module for the GE Fanuc 90-30 PLC series, suitable for precise stepper motor control and commonly used for positioning, control, and motion management of automation equipment.

Main features:

compatibility

Specially designed for the GE Fanuc 90-30 PLC series, it can be directly inserted into the PLC rack and fully integrated with the PLC control system.

Compatible with Horner Electric's other automation equipment, suitable for various industrial automation systems.

control function

Stepper motor control: Supports unipolar and bipolar stepper motors with precise speed and position control.

Pulse output: Supports precise stepper motor control through high-speed pulse output (PTO), suitable for applications that require precise positioning.

Current regulation: Supports current regulation function, suitable for stepper motors of different specifications, optimizing motor performance and power consumption.

performance

Supports multiple stepper motor models and provides adjustable current settings to maximize motor performance.

Provide maximum 4-step motor control, allowing for multi axis motion control.

Installation and Configuration

Adopting rack mounted installation, the installation process is simplified by inserting the GE Fanuc 90-30 PLC rack.

Configuration and programming can be done through Logicmaster 90 or Proficy Machine Edition software.

diagnostic function

Equipped with LED indicator lights, displaying module status, input/output status, and fault warnings for easy operation and maintenance.

Provide self diagnostic function to help quickly detect and troubleshoot faults, ensuring the stable operation of the equipment.

Application areas:

Automated production line (used for precise motion control of equipment such as robotic arms and conveyor belts)

CNC machine tool (high-precision stepper motor positioning)

Packaging machinery (precise control of movement and positioning during the packaging process)

Robot technology (motion control driven by stepper motors)

Medical equipment (devices used for high-precision position control)

Product imag
