Product Details Introduction

HORNER ELECTRIC HE693THM884J is a thermocouple input module designed for the GE Fanuc 90-30 PLC series. It is specifically designed to receive temperature signals from thermocouple sensors and convert them into digital signals for PLC processing. This module is widely used in temperature monitoring and process control systems, especially for industrial automation applications that require high-precision temperature measurement.

Main features:

compatibility

This module is designed specifically for the GE Fanuc 90-30 PLC series and is compatible with other Horner Electric series devices.

Support configuration and programming with Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing PLC systems.

Channel

Provide 8 independent thermocouple input channels that can simultaneously receive signals from multiple thermocouple sensors.

Each input channel supports multiple types of thermocouples, including K-type, J-type, T-type, E-type, R-type, S-type, B-type, and N-type.

Wide range of thermocouple types supported

Supports multiple thermocouple types such as K, J, T, E, R, S, B, N, etc.

Allow users to choose the appropriate thermocouple type for their application, flexibly applying it to different temperature ranges and accuracy requirements.

Temperature measurement range

Support temperature measurement range of various thermocouples:

K-type:- 270 ° C to+1372 ° C

J-type:- 210 ° C to+1200 ° C

T-shaped:- 200 ° C to+400 ° C

Type E:- 200 ° C to+900 ° C

R/S type: 0 ° C to+1768 ° C

Type B:+ 400 ° C to+1820 ° C

N-type:- 200 ° C to+1300 ° C

The measurement range of various thermocouples varies according to different models and is suitable for various industrial environments.

Cold end compensation function

Equipped with automatic cold junction compensation function to ensure that temperature changes at the cold junction during the measurement process do not affect the signal accuracy of the thermocouple, thereby ensuring the accuracy and reliability of temperature data.

High precision and resolution

Accuracy: ± 0.25%

Resolution: Depending on the type of thermocouple, the resolution can reach 0.1 ° C or higher.

Real time data collection and processing

Support digital output, real-time transmission of temperature data to PLC system for further processing and decision-making by the control system.

Temperature data can be read and controlled through PLC programs.

Status indication and alarm function

Equipped with LED indicator lights to display module status, input signals, and fault warnings, facilitating real-time monitoring of equipment operation status by operators.

Provide alarm function to indicate equipment malfunction or abnormal temperature.

Product imag
