HORNER ELECTRIC HE693THM889C Analog Thermocouple Input Module

HORNER ELECTRIC HE693THM889C Analog Thermocouple Input Module

Product Details Introduction

HORNER ELECTRIC HE693THM889C is an analog thermocouple input module designed specifically for the GE Fanuc 90-30 PLC series, capable of receiving analog signals from thermocouples and converting them into digital signals. It is widely used in industrial automation control systems, especially in applications that require high-precision temperature monitoring and control.

Main features:

Compatibility and Integration

Specially designed for GE Fanuc 90-30 PLC series, suitable for Horner Electric series automation control systems.

Configuration and programming can be done through Proficy Machine Edition or Logicmaster 90 software.

Perfectly compatible with other Horner Electric products and easy to integrate with existing systems.

Channel

Provide 8 independent analog thermocouple input channels, each of which can receive signals from thermocouple sensors.

The module supports multiple types of thermocouples, including K-type, J-type, T-type, E-type, R-type, S-type, B-type, N-type, etc.

Thermocouple type support

Supports common types of thermocouples such as K, J, T, E, R, S, B, N, etc.

This module provides temperature measurement based on different thermocouple types and can select the appropriate thermocouple type according to different working environments and requirements.

Accuracy and Resolution

Provide high-precision temperature data acquisition function, with an accuracy of ± 0.25% or higher, ensuring accurate measurement and reliable data output.

The resolution can reach 0.1 ° C, allowing temperature changes to be captured in a timely and accurate manner.

Automatic cold end compensation function

This module has an automatic cold end compensation function, which can compensate for temperature changes in the cold end of thermocouples and ensure the accuracy of temperature data.

Even if the temperature at the cold end changes, it can accurately reflect the temperature at the thermocouple end, improving the reliability of the data.

Analog signal conversion

This module supports analog signal input and converts it into digital signals for subsequent processing and control.

The output digital signals can be further processed through PLC programs for temperature control or alarm systems.

Status indication and alarm function

Equipped with LED indicator lights to display the operating status of the module, including signal input status, normal operation, and fault warnings.

Provide alarm output to promptly issue a warning when the temperature exceeds the set range or the module malfunctions.

Multi-channel Design

Supports up to 8 independent channels, allowing users to connect multiple thermocouple sensors simultaneously for multi-point temperature monitoring.

Each channel has independent input and output settings, suitable for complex industrial control systems.

Product imag
