HORNER ELECTRIC HE693ADC816D Analysis Input Module

HORNER ELECTRIC HE693ADC816D Analysis Input Module

Product Details Introduction

HORNER ELECTRIC HE693ADC816D is a high-performance analog input module designed specifically for the GE Fanuc 90-30 PLC series. This module supports multi-channel analog signal input and can perform precise signal acquisition and analysis, widely used in industrial automation systems that require high-precision data acquisition.

Main features:

Compatibility and Integration

Specially designed for the GE Fanuc 90-30 PLC series and compatible with other control products from Horner Electric.

It can be configured and programmed through Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing automation systems.

Channel

Provide 16 independent analog input channels, each supporting differential input or single ended input, suitable for various analog signal acquisition scenarios.

Each input channel can handle multiple types of analog signals, such as voltage, millivolts, milliamps, etc.

High precision and high resolution

Resolution: 16 bit resolution, capable of accurately capturing subtle analog signal changes.

Accuracy: ± 0.1% or higher, ensuring that the collected data is very accurate, suitable for control systems that require high precision.

Input Signal Type

Supports voltage input (0-10V, ± 10V, etc.) and current input (4-20mA, etc.), enabling the module to meet the input requirements of different types of signals.

Supporting differential input mode, it can effectively suppress electrical noise and provide more stable signal acquisition.

Sampling and update rate

Support high sampling rate, able to quickly collect data and transmit it in real-time to the PLC system.

Different update frequencies can be configured according to requirements to ensure real-time data acquisition and processing.

Input channel configuration and flexibility

Each channel supports independent configuration, and users can choose differential or single ended mode, and configure different input ranges as needed.

Support custom input calibration to meet the requirements of specific devices or sensors.

Status indication and alarm function

Equipped with LED indicator lights to display module status, including input signal status, module operation status, and fault warnings.

Provide alarm function, which will issue a warning when the input signal exceeds the set threshold, facilitating timely action.

Scalability and compatibility

The Horner Electric series of I/O expansion modules can further expand the number of input channels to meet the needs of large-scale automation systems.

Compatible with other Horner Electric automation control equipment, it can form an efficient and flexible automation control system.

Product imag
