HORNER ELECTRIC HE693THM446 Temperature Analysis Module

HORNER ELECTRIC HE693THM446 Temperature Analysis Module

Product Details Introduction

HORNER ELECTRIC HE693THM446 is a temperature input module designed specifically for Horner Electric series automation control systems, widely used in industrial automation systems that require temperature monitoring and control. This module collects analog signals from different types of temperature sensors (such as thermocouples and RTDs) for accurate temperature measurement, and transmits the data to the control system, supporting real-time temperature monitoring and analysis.

Main features:

Supports multiple types of temperature sensors

HE693THM446 supports thermocouple and RTD signal input.

Compatible with various common types of thermocouples, such as K-type, J-type, T-type, E-type, as well as Pt100, Pt1000 and other types of RTD sensors.

High precision and high resolution

Providing a resolution of up to 16 bits, it can accurately capture temperature changes and ensure high-precision data acquisition.

Supports a wide temperature range and can adapt to various temperature measurement needs, ensuring stable operation of the system in changing environments.

Multi channel input

Provide multiple temperature input channels and support connecting multiple temperature sensors simultaneously.

It can achieve multi-point temperature monitoring, suitable for application scenarios that require monitoring the temperature of multiple devices or areas simultaneously.

Accurate signal conversion and processing

The HE693THM446 module converts the analog signal of the temperature sensor into a digital signal through a built-in high-precision analog-to-digital converter (ADC), ensuring the accuracy of temperature data.

Support temperature compensation function, which can provide more accurate temperature measurement results based on external environmental factors, such as cold end compensation of thermocouples.

Real time temperature monitoring and alarm function

Support real-time temperature data collection and monitoring, and can perform real-time analysis based on temperature data.

Provide temperature threshold setting and alarm function. When the temperature exceeds the set safe range, the system will issue an alarm to take timely measures.

Diagnosis and troubleshooting

This module is equipped with status indicator lights, which can display the working status and fault information of the module, making it convenient for operators to conduct quick diagnosis.

Capable of detecting signal distortion, disconnection, and other issues, and promptly alerting to ensure the reliability and stability of the system.

Easy to configure and integrate

By coordinating with Horner Electric's other devices and software (such as Proficy Machine Edition) for configuration and integration, system setup can be quickly achieved.

Visualize and monitor data through HMI (Human Machine Interface) or SCADA system to improve operational efficiency.

Durable and sturdy, suitable for industrial environments

The HE693THM446 module has industrial grade reliability and can withstand harsh working environments such as high temperature, humidity, and vibration.

The protective design ensures its continuous and stable operation in industrial automation, suitable for long-term use.

Product imag
