Product Details Introduction

HORNER ELECTRIC HE693ADC405A is an analog voltage input module used in Horner Electric's automation control system, designed to provide high-precision analog signal acquisition and processing capabilities. This module is commonly used in industrial automation, process control, and other fields. By converting analog voltage signals into digital signals, it helps control systems to monitor and control various devices in real time.

Main features:

Multi channel input

The HE693ADC405A module provides multiple analog voltage input channels, which can simultaneously access multiple voltage signals for multi-point data acquisition.

Usually providing 4-8 channels of input, it can achieve real-time monitoring of multiple sensors or signal sources.

High resolution and precision

This module has a resolution of up to 16 bits and can accurately convert input analog voltage signals into digital signals.

High precision, suitable for application scenarios that require high-precision data collection.

Wide input voltage range

Supports multiple voltage ranges, such as common 0-10V, ± 10V, 0-5V, etc., and can adapt to analog voltage signals in various industrial environments.

It can be flexibly configured according to different application requirements to meet the voltage acquisition needs of various devices.

Real time data collection and processing

The module provides high-speed data acquisition, enabling real-time acquisition of input signals and digital processing.

Support fast signal updates and data transmission, enabling the control system to respond promptly to changes in the external environment.

Isolation and anti-interference capability

The HE693ADC405A module typically adopts a signal isolation design, effectively avoiding the impact of electrical noise, interference, and other factors on signal transmission.

Has strong anti-interference ability and adapts to complex electromagnetic interference in industrial environments.

Temperature and power compensation

This module supports temperature compensation function, which can dynamically adjust according to temperature changes to ensure measurement accuracy.

Provide power compensation to ensure stable operation under different power conditions.

Programmable functionality and flexible configuration

The HE693ADC405A module is compatible with other control devices of Horner Electric and can seamlessly integrate with PLC and HMI systems.

Parameter configuration and debugging are carried out through programming software such as Proficy Machine Edition, supporting flexible user customization needs.

Data Visualization and Monitoring

Data can be visualized through HMI or SCADA systems, facilitating real-time monitoring and data analysis for operators.

Provide an intuitive interface for viewing real-time voltage data for each input channel.

Product imag
