CDP312R 64378660G Control Panel

CDP312R 64378660G Control Panel

Product Details Introduction

1. Product Overview

model: CDP312R

Order number: 64378660G

manufacturer: ABB

Equipment type: Industrial frequency converter/driver dedicated control panel

Applicable series: ABB frequency converters such as ACS550/ACS580/ACS880

2. Core functions

Human computer interaction interface:

4-line LCD display (with backlight)

Multi functional navigation key+numeric keypad

Parameter configuration:

Real time monitoring of operating parameters (current, voltage, frequency, etc.)

Quickly modify driver parameters

Control operation:

Local start/stop control

Fault reset function

Status indication:

LED status light (running, fault, warning)

3. Technical parameters

Parameter specifications

Display area 4 lines x 20 characters (with backlight)

Communication interface RS485 (Modbus RTU protocol)

Protection level IP65 (front panel)/IP20 (rear)

Working temperature -10 ℃~+50 ℃

Storage temperature -25 ℃~+70 ℃

The power supply voltage is supplied through a frequency converter (24VDC)

Button lifespan ≥ 1 million operations

Product imag
