QUNT-PS/1AC/24DC/20 power supply module

QUNT-PS/1AC/24DC/20 power supply module

Product Details Introduction

QUINT-PS/1AC/24DC/20 is a high-performance DIN rail power module launched by Phoenix Contact, designed to provide stable DC power for industrial automation and control systems.

main features

Input voltage range: Supports single-phase AC input, with a voltage range of 100 V AC to 240 V AC, suitable for different global power grid standards.

Output performance:

Rated output voltage: 24 V DC

Rated output current: 20 A, providing 480 W of power, suitable for high load equipment

Dynamic power boost: can provide up to 30 A of current in a short period of time (lasting for 5 seconds), suitable for the starting needs of motors or large loads

SFB technology (selective fuse): can instantly provide 120 A current (lasting 12 milliseconds) in the event of a short circuit, ensuring fast triggering of standard circuit breakers, precise fault location, and improving system safety

High efficiency: At 230 V AC input, the efficiency can reach 94%, reducing energy consumption and heat, and improving system stability

Installation method: DIN rail installation is adopted, supporting screw connection for easy integration of control cabinet

application area

Industrial automation: providing stable 24V DC power supply for control equipment such as PLC and HMI

Process Control: Suitable for powering sensors and actuators in industries such as petroleum, chemical, and pharmaceutical

Power system: used for supplying power to relay protection devices and communication equipment in substations and distribution systems

Transportation: Providing reliable power supply in application scenarios such as railway signal systems, airport lighting, and traffic control equipment

QUINT-PS/1AC/24DC/20 is widely used in industrial environments that require high availability and stability due to its high reliability and powerful protection functions.

Product imag
