FAZ-C10/2 Circuit Breaker

FAZ-C10/2 Circuit Breaker

Product Details Introduction

FAZ-C10/2 is a miniature circuit breaker (MCB) produced by Schneider Electric, mainly used for overload protection and short circuit protection in low-voltage electrical systems. This type of circuit breaker is widely used in residential, commercial, and industrial electrical distribution systems, with high reliability and safety, ensuring the stable operation of electrical equipment and circuits.

main features

Overload and short circuit protection: FAZ-C10/2 circuit breaker has overload and short circuit protection functions. When the current exceeds the set value, it automatically disconnects the circuit to prevent damage to electrical equipment.

Contact protection design: This circuit breaker is equipped with a reliable contact protection mechanism, which can quickly respond to faults in the electrical system, provide timely power-off protection, and avoid safety hazards such as fires.

Widely applicable: This circuit breaker is suitable for low-voltage distribution systems in households, commercial buildings, and industrial environments, protecting circuits from damage caused by overload and short circuits.

Bipolar design: FAZ-C10/2 is a bipolar circuit breaker that provides two sets of contacts (bipolar), suitable for dual phase power systems and capable of handling protection requirements for high current loads.

High reliability and durability: This circuit breaker is made of high-quality materials and advanced technology, with a long service life and high reliability, ensuring the long-term safe and stable operation of the electrical system.

Compact design: FAZ-C10/2 has a compact exterior design that complies with DIN rail installation standards, making it easy to install in distribution boxes or control panels and saving space.

technical specifications

Rated current: 10A, suitable for overload protection of small and medium-sized loads.

Rated voltage: typically suitable for 230V AC or 400V AC (depending on specific configuration), meeting the standard voltage of household or commercial power systems.

Polarity: 2-pole, suitable for bipolar circuits, widely used for two phases in distribution systems.

Breaking ability: FAZ-C10/2 circuit breaker has a high breaking ability, which can quickly cut off the peak current and avoid equipment damage.

Characteristic curve: C-type characteristic curve, suitable for most load types, especially electric motors and electrical equipment. It can quickly disconnect the circuit in the event of a real fault (such as a short circuit) without tripping under short-term overload conditions.

Working temperature range: typically -25 ° C to+70 ° C, suitable for various environments and working conditions.

Installation method: Complies with DIN rail installation standards, making it easy to install in standard distribution boxes.

Product imag
