DO820 digital output relay module

DO820 digital output relay module

Product Details Introduction

DO820 is a digital output relay module produced by ABB, used in industrial automation and process control systems. It is suitable for AC 230V or DC 24V loads and can drive solenoid valves, relays, and other actuating devices.

main features

16 digital outputs, each channel has high load capacity.

Relay isolation provides higher electrical safety.

Supports high voltage loads and is suitable for AC 230V and DC 24V devices.

Modular design, compatible with ABB S800 I/O series, easy to integrate.

LED status indicator for easy diagnosis and maintenance.

technical specifications

Output channel: 16 relay outputs.

Rated voltage: AC 230V / DC 24V。

Maximum output current: 2A/channel.

Response time:< 10ms, ensure fast switching.

Installation method: DIN rail or rack installation.

application area

Process control: suitable for factory automation and industrial control systems.

Power system: used to control circuit breakers, relays, and alarm systems.

Building automation: used for lighting, air conditioning, and other building control systems.

DO820 has high voltage compatibility and relay isolation protection, making it a reliable choice in industrial control and automation systems.

Product imag
