AI810 Analog Input Module

AI810 Analog Input Module

Product Details Introduction

AI810 is an analog input module produced by ABB, belonging to the S800 I/O series, used for analog signal acquisition in process automation and industrial control systems. This module is capable of processing current (mA) or voltage (V) signals and is widely used for data acquisition in devices such as sensors and transmitters.

main features

8 analog input channels, supporting multiple signal types.

Supports current/voltage input and is suitable for various industrial sensors.

High precision A/D conversion ensures the accuracy of data acquisition.

Fault detection function, including wire breakage detection, improves system reliability.

Compatible with ABB S800 I/O system, easy to integrate into DCS control systems such as AC 800M.

technical specifications

Input type:

Voltage mode: ± 10V

Current mode: 0/4-20mA

Number of channels: 8 independent input channels

Resolution: 12 bit A/D conversion

Scanning time: 2ms/channel, supports fast data updates

Installation method: DIN rail or rack installation

Isolation protection: Electrical isolation between channels and systems to improve anti-interference ability

Product imag
