DILA-XH11 contactor

DILA-XH11 contactor

Product Details Introduction

DILA-XH11 is an auxiliary contactor module produced by Eaton, mainly used to expand the functionality of the DILA series contactors. It adds one normally open (NO) and one normally closed (NC) contact, which can be used for signal control, status indication, and circuit logic conversion.

main features

1NO+1NC contact configuration, suitable for different control requirements.

It can be directly installed on the DILA contactor without additional wiring, making expansion convenient.

High durability contacts ensure long-term reliable operation.

Modular design, compatible with DILM/DILA series main contactors.

Supports DIN rail installation for easy integration into control cabinets.

technical specifications

Contact configuration: 1NO+1NC (normally open+normally closed).

Rated current: 10A.

Rated voltage: AC/DC 24V, 110V, 230V (depending on the specific model).

Mechanical lifespan: over 10 million operations.

Working temperature:- 25 ° C to+55 ° C.

Installation method: directly plug into the DILA contactor or install on a DIN rail.

application area

Industrial automation: Used for auxiliary function expansion of PLC and relay control systems.

Power system: signal switching, status indication, and circuit logic control.

Mechanical equipment: Used in conjunction with the main contactor to achieve logical control of motors or other equipment.

DILA-XH11 has a compact structure and easy installation, making it an ideal expansion module for DILA series contactors, widely used in industrial automation and electrical control systems.

Product imag
