Module CI871AK01 (3BSE092693R1) is a commonly used industrial communication interface module in ABB control systems, widely used in AC 800M control systems to achieve communication between controllers and field network devices.

Basic information

Project Content

Model CI871AK01

Order number 3BSE092693R1

Manufacturer ABB

Series AC 800M Controller/800xA System

Module type communication interface module (PROFIBUS communication)

FUNCTIONAL OVERVIEW

CI871AK01 is an interface module used for PROFIBUS DP (Decentralized Peripherals) communication, commonly used as a slave communication interface for AC 800M controllers, to connect the following devices:

Remote I/O module

Variable frequency drive, motor driver

Intelligent on-site equipment (with PROFIBUS interface)

Technical Parameter

Project parameter description

Communication protocol PROFIBUS DP-V0/V1 Slave

Transmission rate up to 12 Mbit/s (automatic baud rate detection)

Connection method through PROFIBUS 9-pin D-sub interface

Address configuration can be set through DIP switches

Module size compatible with standard AC 800M module (installed on modular rack)

The power demand is supplied by the motherboard, without the need for a separate power source

LED indicates communication status, fault status, module status, etc

Operating at an ambient temperature of -25 ° C to+70 ° C

Installation method: DIN rail/800xA system specific slot
