GFD233A103 3BH02294R0103 Controller

GFD233A103 3BH02294R0103 Controller

Product Details Introduction

GFD233A103 (order number: 3BH022294R0103) controller, the following is a detailed information summary:

1、 Basic Information

Product model: GFD233A103

Order Number: 3BH022294R0103

manufacturer: ABB

Equipment type: Controller module/Control unit

System: Commonly used in ABB Symphony Plus, INFI 90, or Freelance systems, and may also be used in ABB DCS submodule systems.

2、 Function and purpose

This module is a core controller in ABB control system, with the following functions:

Main control function: used for collecting process data, executing logic control, and communication management, it is the brain module of the automation system.

Data communication: Capable of communicating with upper level computers (such as HMI, SCADA) and lower level field devices.

Real time processing: supports high-speed logic judgment, data analysis, and instruction issuance, commonly used in the field of continuous process control.

Multi tasking: supports independent logical processing of multiple processes or subsystems.

3、 Technical parameters (reference)

Project parameter description

Power supply voltage 24V DC (powered by the base plate)

Installation method: Plug in module, DIN rail or dedicated rack

Multiple communication ports with interface types (such as RS485/Ethernet/MODBUS/ABB proprietary protocol)

System compatibility Symphony Plus INFI 90、 Or the Freelance series

Working temperature -25 ° C to+70 ° C (industry standard)

Redundancy support can support controller redundancy configuration (primary backup switching)

Programming configuration using ABB Control Builder or Symphony Plus Engineering tools

Product imag
