Alcatel Lucent 3HE00101AB Switch Port Module

Alcatel Lucent 3HE00101AB Switch Port Module

Product Details Introduction

The Alcatel Lucent 3HE00101AB Switch Port Module is a high-performance interface expansion board in Alcatel Lucent (now part of Nokia) communication equipment, used to provide high-speed Ethernet ports and widely used in its carrier grade devices, such as the 7705 Service Aggregation Router (SAR) or 7450 ESS (Ethernet Service Switch) series.

1、 Basic Information

Project Description

Model 3HE00101AB

Device type: Switch port module/Ethernet interface board

Manufacturer Alcatel Lucent (now Nokia)

The adaptation platform may be used for 7x50 series (such as 7750 SR, 7705 SAR) switching routing devices

The main purpose is to provide multi port Gigabit or 10 Gigabit Ethernet connections for network access and aggregation

2、 Main functions

Port Expansion

Add multiple physical Ethernet ports to the main switching/routing equipment to connect user devices, upstream cores, or downstream access nodes.

High performance data processing

Supports line speed forwarding, low latency and high throughput, suitable for backbone aggregation or enterprise edge networks.

Multiple interface support

Supports RJ-45, SFP/SFP+optoelectronic hybrid ports to meet different speed and link medium requirements.

Support rich protocol stack

Including advanced network functions such as VLAN, QinQ, MPLS, IP Routing, QoS, ACL, etc.

3、 Technical parameters (typical configuration, for reference)

Parameter Description

Port types may include 8-24 1G or 10G ports (SFP/RJ45)

Speed support: Supports 10/100/1000 Mbps or 1/10 Gbps (depending on configuration)

Hot swappable support

Module type IOM (Interface Option Module) or Line Card

The power demand is supplied through the device chassis

Equipment compatibility needs to be used in conjunction with the main control board (CPM) and chassis backplane

The management method is unified by the main system and supports SNMP, CLI, and web interfaces

Product imag
