Product Details Introduction

1、 Product Overview

The Alcatel Lucent 644-0091-001 interface board is a communication expansion module used in telecommunications systems. It is mainly used to provide additional physical interfaces in communication devices to complete network signal access, conversion, distribution, and management. It is commonly used in access networks, transmission systems, core routing platforms, or wireless control systems.

2、 Main functions

Communication interface extension:

Provide multiple physical ports (such as Ethernet, fiber optic, serial, etc.) for connecting external network devices or other modules.

Protocol adaptation and data processing:

Support adaptation, forwarding, and basic processing of data from different communication protocols.

System management integration:

It can be managed and monitored through the device control system, and some models support hot plugging and remote fault detection.

Signal conversion and routing:

Provide conversion bridging functions between signals of different rates or types, such as electrical/optical signal conversion, rate matching, etc.

3、 Technical parameters (estimated based on similar interface boards)

Interface types: RJ45 electrical port, SFP optical port, RS232 serial port, etc. (specific to device configuration)

Supporting protocols: Ethernet (10/100/1000Mbps), serial communication protocol, or dedicated communication protocol

Installation method: Standard slot type, suitable for Alcatel Lucent communication equipment rack system

Power supply: Unified power supply from the main equipment

Working temperature:- 5°C ~ +55°C

Management support: SNMP, CLI command line, NMS network management system integration

4、 Typical Application Device Platform

Alcatel Lucent ISAM series access devices

7750 SR series routing platform

1850 TSS Optical Transmission Platform

Wireless base station control equipment (such as BBU/RNC)

Physical Communication Channels in OSS/NMS Network Management System

5、 Deployment and usage suggestions

The plugging and unplugging operation should follow the manufacturer's safety procedures. If hot plugging is supported, the module status needs to be confirmed

Confirm module compatibility with system software version before installation

It is recommended to regularly monitor the status and traffic of the interface board through a network management system

It is recommended to backup the relevant configuration data before replacement

Product imag
