ALCATEL-LUCENT 3AL00320BC01 Optical and Electrical Board

ALCATEL-LUCENT 3AL00320BC01 Optical and Electrical Board

Product Details Introduction

ALCATEL-LUCENT 3AL00320BC01 is an Optical Electrical Board commonly used in optical communication systems, responsible for optical to electrical signal conversion or optical transmission control. The following is an analysis of its possible application areas and functional characteristics:

1. Main application areas

(1) Optical Transmission System (OTN/DWDM)

Wavelength division multiplexing equipment: may be used on Alcatel Lucent 1830 PSS series optical transmission platforms as optical path cards (such as OTU boards), supporting wavelength conversion or optical signal amplification.

Fiber optic backbone network: Processing high-speed optical signals (such as coherent optical transmission of 100G/200G/400G) in long-distance or metropolitan optical networks.

(2) Fiber optic access network (PON/FTTx)

OLT (Optical Line Terminal): In GPON/XGS-PON devices, it may be used as an upstream optical interface module to connect to the core network.

ONU/ONT management: supports optical to electrical signal conversion in fiber to the home (FTTH) scenarios.

(3) Data Center Interconnection (DCI)

Optical module plug-in board: In data center switches or routers, it provides high-speed optical interconnection (such as QSFP28/CFP2 interfaces) and supports low latency data transmission.

(4) Mobile Forward/Back Transmission (5G/C-RAN)

Wireless optical transmission: used for the forward transmission (such as eCPRI) or return network of 4G/5G base stations, to achieve the conversion of optical signals and electrical signals.

2. Functional characteristics (speculated)

Optoelectronic conversion: Integrated laser (Tx) and photodetector (Rx), supporting single-mode or multi-mode optical fibers.

Speed support: May cover speeds of 1G/10G/25G/100G, compatible with OTN (G.709) or Ethernet standards.

Pluggable design: Some models may support hot swapping (such as SFP+/QSFP+form) for easy maintenance and upgrades.

Management function: Built in digital diagnostic monitoring (DDM), supporting real-time monitoring of parameters such as optical power and temperature.

Product imag
