ALCATEL-LUCENT 3DH03164AAAA transmitter module

ALCATEL-LUCENT 3DH03164AAAA transmitter module

Product Details Introduction

1. Product positioning

This module belongs to the optical communication transmission unit, which is used to convert electrical signals into optical signals (E/O conversion). It is mainly deployed in Alcatel Lucent optical transmission and broadband access equipment, supporting high-speed data fiber transmission.

2. Core functional features

Parameter Technical Specifications (Typical Values) Description

Single mode fiber (SMF) suitable for wavelengths of 1310nm/1550nm

Transmission rates of 1G/10G/25G support SDH, Ethernet, and OTN protocols

Transmitting power -3dBm~+5dBm meets Class 1 laser safety standards

Transmission distance of 10km/40km/80km, available in different power versions

Design of interface type SFP+/XFP pluggable optical module

Operating temperature -5 ° C~+70 ° C Industrial grade temperature adaptability

3. Typical application scenarios

(1) Optical Transmission Network (OTN/DWDM)

As a customer side optical interface in the 1830 PSS platform, it achieves optoelectronic conversion and wavelength multiplexing of business signals.

Support submodules for 100G/200G coherent transmission systems (such as those used inside CFP2 optical modules).

(2) Broadband access (PON/FTTx)

As the upstream optical transmission module of GPON OLT, it connects to the metropolitan core network.

Provide 10G LAN-PHY or WAN-PHY interfaces in enterprise dedicated lines.

(3) Data Center Interconnection (DCI)

Used for short/long distance optical interconnection of data center switches (such as 7750 SR), supporting standards such as SR/LR/ER.

4. Hardware compatibility

Applicable equipment series:

Optical transmission: 1830 PSS, 1626 LM

Router: 7750 SR, 7450 ESS (requires corresponding interface card)

Wireless devices: used for 5G fronthaul (eCPRI) or backhaul (IP-RAN)

Mechanical specifications:

Packaging: pluggable (SFP+/XFP) or fixed (please refer to specific model)

Power consumption:< 1.5W (SFP+),<3.5W (XFP)
