ALCATEL-LUCENT 3AL78818AAAC Communication Module

ALCATEL-LUCENT 3AL78818AAAC Communication Module

Product Details Introduction

1. Product positioning

This module is a high-performance business processing module in Alcatel Lucent (now Nokia) communication systems, mainly used for optical transmission and packet switching equipment, responsible for business aggregation, protocol conversion, and traffic management functions.

2. Core functional features

Characteristic Technical Description

Multi service support for simultaneous processing of TDM, Ethernet, and IP services, supporting mixed transmission of circuit switching and packet switching

High density interface provides multiple 10G/25G optical or electrical ports, supporting modular interface board expansion

Intelligent traffic management has HQQoS (Hierarchical Quality of Service) and traffic shaping functions, supporting 5 levels of business priority

Hardware accelerated integrated dedicated network processor, supporting MACsec encryption and deep packet inspection (DPI)

The hot swappable design complies with NEBS Level 3 standards and supports online replacement and 1+1 redundant configuration

3. Typical application scenarios

Metropolitan Access Network:

Implementing GPON to metropolitan core network business aggregation in 7350 OLT equipment

Clock synchronization supporting Mobile Backhaul (IP-RAN) (1588v2)

Enterprise dedicated line service:

Provide E1/T1 to Ethernet business conversion

Support VPLS and VPWS layer 2 VPN services

5G network applications:

Front haul network used in CU/DU separation architecture

Support low latency transmission of eCPRI protocol (<100 μ s)

4. Technical specifications and parameters

Physical parameters:

Size: Complies with ATCA standards (8U height)

Power consumption: typical value of 85W, maximum 120W

Heat dissipation: front and rear facing ventilation design

Product imag
