ALCATEL-LUCENT 3FE29191AA AA 05 Circuit Board

ALCATEL-LUCENT 3FE29191AA AA 05 Circuit Board

Product Details Introduction

ALCATEL-LUCENT 3FE29191AA AA 05 Circuit Board Technical Specifications

1. Product Overview

Model: 3FE29191AA AA 05

Type: Business Processing/Interface Circuit Board

Purpose: Used for Alcatel Lucent (now Nokia) broadband access or optical transmission equipment, providing business aggregation, protocol conversion, or interface expansion functions.

2. Core functions and features

(1) Interface support

Ethernet interface: 10/100/1000BASE-T (RJ45) or SFP (1G/10G) optical port

Traditional TDM interface: optional support for E1/T1 (for voice or dedicated line services)

Optical transmission interface: may support GPON/XGPON (if used for OLT devices)

(2) Business processing capability

Multi service adaptation: supports IP, MPLS, TDM hybrid services

Traffic management: supports QoS priority scheduling and ACL filtering

Low latency forwarding: hardware accelerated processing, latency<50 μ s

(3) High reliability design

Hot swappable support: can be replaced while the device is running

Redundancy protection: Supports 1+1 backup (requires device architecture support)

(4) Energy saving and heat dissipation

Intelligent power management: dynamically adjust power based on traffic

Fanless design: Some versions use passive cooling

3. Typical application scenarios

(1) Broadband Access Network (FTTx)

As a business card in the 7360 ISAM OLT, it provides GPON/XGS-PON user access

Support the integration of home broadband (HSI), IPTV, and VoIP services

(2) Enterprise dedicated line access

Used for 7705 SAR equipment, providing enterprise Ethernet dedicated line (E-Line/E-LAN)

Support CESoP (Circuit Simulation over Packet) to achieve TDM over IP

(3) Mobile backhaul (IP-RAN)

Carrying CPRI/eCPRI traffic in 4G/5G base station backhaul network

Support 1588v2 clock synchronization

Product imag
