ALCATEL-LUCENT 3DEC15905AA Control Processor Module

ALCATEL-LUCENT 3DEC15905AA Control Processor Module

Product Details Introduction

1. Product positioning

Core Control Unit: As the main control engine for Alcatel Lucent (Nokia) high-end routing/switching equipment

System level functionality: responsible for device management, routing computation, protocol processing, and network control plane operations

2. Key characteristics

Characteristic Technical Description

Processing architecture: multi-core network processor (NPU)+x86 control CPU

Memory configuration: 16GB DDR4 (data plane)+8GB (control plane)

Storage capacity 64GB SSD (system image+log storage)

The protocol supports a full range of IP/MPLS protocol stacks (BGP/OSPF/IS-IS/RSVP-TE, etc.)

Management interface 10/100/1000BASE-T out of band management port+USB configuration port

3. Performance parameters

Routing table capacity: ≥ 2 million IPv4/v6 routing entries

Forwarding performance: Supports line speed processing of 400Gbps business traffic

Protocol convergence: IGP convergence time<1 second (full mesh topology)

Temperature range: 0 ° C~45 ° C (commercial grade)/-5 ° C~55 ° C (enhanced version)

4. Redundant design

Primary backup switching: supports 1+1 hot backup (switching time<200ms)

Fault isolation: physical separation of control plane and data plane

Health monitoring: Real time monitoring of CPU/memory/temperature status

5. Typical application scenarios

Core router (7750 SR-12/7950 XRS):

Handle network wide routing calculations and MPLS LSP establishment

Support SDN controller docking (OpenFlow/NETCONF)

Business Router (7705 SAR-H):

Implement enterprise VPN business control (L3VPN/L2VPN)

Carrying 5G mobile backhaul services

Data Center Gateway:

Provide EVPN/VXLAN control function

Support network virtualization overlay

6. System compatibility

Hardware platform:

7750 SR-7/12 series

7950 XRS series

7705 SAR-H series

Software requirements:

SR OS 16.0.R6 and above versions

Basic License and Advanced Feature License need to be activated

Product imag
