ALCATEL-LUCENT 8DG02672AAAC Ethernet Port Module

ALCATEL-LUCENT 8DG02672AAAC Ethernet Port Module

Product Details Introduction

ALCATEL-LUCENT 8DG02672AAAC Ethernet Port Module Technical Specifications

1. Product Overview

Model: 8DG02672AAAC

Type: High density Ethernet business interface module

Positioning: Used for Alcatel Lucent (Nokia) core routing/switching equipment, providing high-performance Ethernet access capability

2. Core functional features

(1) Interface configuration

Port type:

Supports 10G SFP+(default) or 25G SFP28 (also compatible with optical module)

Optional 1G/10G Base-T (RJ45 electrical port, some versions support it)

Port density:

Single module provides 8 × 10G or 4 × 25G ports (hardware configurable)

(2) Business processing capability

Traffic forwarding:

Wire speed forwarding (non blocking), supporting Jumbo Frame (9K MTU)

Low latency design (<5 μ s, 64 byte grouping)

Protocol support:

Second layer protocol: IEEE 802.1Q VLAN、STP/RSTP/MSTP

Three layer protocol: IPv4/IPv6、ICMP/ARP/VRRP

Business functions: MPLS, QinQ, VXLAN (software support required)

(3) Advanced features

Quality of Service (QoS):

Supports 8 priority queues (802.1p/DSCP)

Shaping and Policing of Traffic

Security features:

MAC address filtering, port security (MAC Lock)

ACL access control (based on IP/port/VLAN)

(4) Reliability Design

Hot swappable: supports online replacement (OIR)

Redundancy protection: Supports LACP link aggregation (up to 8 member ports)

Fault detection: Port level BERT (bit error rate test)

Product imag
