ALCATEL-LUCENT 3FE25676BA Optical and Electrical Board

ALCATEL-LUCENT 3FE25676BA Optical and Electrical Board

Product Details Introduction

ALCATEL-LUCENT 3FE25676BA Optical and Electrical Board Technical Specifications

1. Product Overview

Model: 3FE25676BA

Type: Optoelectronic Hybrid Interface Board

Positioning: Used for Alcatel Lucent (Nokia) optical transmission and IP equipment to achieve optical to electrical signal conversion and business access

2. Core functional features

Functional Technical Description

Optoelectronic conversion supports bidirectional E/O conversion (1310nm/1550nm wavelength)

Interface type: 10G SFP+optical port+1G/10G Base-T electrical port hybrid configuration

The protocol supports Ethernet/IP/MPLS and is compatible with OTN G.709 encapsulation

Business processing supports L2 switching and L3 routing functions

Clock synchronization supports SyncE and 1588v2 (PTP)

3. Technical parameters

Parameter specifications

The optical interface supports up to 8x10G SFP+

Electrical interface 4x10G Base-T (RJ45)

Transmission distance single-mode 40km (SMF)

Power consumption 45W (typical value)

Working temperature: 0 ° C~50 ° C

4. Typical application scenarios

metropolitan access network

Implementing GPON business aggregation in 7350 OLT equipment

Hybrid networking supporting mobile backhaul (IP-RAN)

Enterprise dedicated line service

Provide E1/T1 to Ethernet business conversion

Support VPLS and VPWS layer 2 VPN services

Data Center Interconnection

Short distance optical interconnect for DCI (≤ 10km)

Support VXLAN over 10G Ethernet

Product imag
