ALCATEL-LUCENT 644-0089-001 interface board

ALCATEL-LUCENT 644-0089-001 interface board

Product Details Introduction

ALCATEL-LUCENT 644-0089-001 Interface Board Technical Specifications

1. Product Overview

Model: 644-0089-001

Type: Multi service interface processing board

Positioning: Used for traditional transmission and access equipment of Alcatel Lucent (Nokia), providing mixed service access capability

2. Core functional features

Characteristic Technical Description

Interface types support E1/T1, 10/100BASE-T, STM-1 hybrid access

Business Processing Implementation of TDM to IP Conversion (CESoP)

Clock synchronization supports BIT clock input/output

Protection mechanism 1+1 board level protection switching

Management function supports TL1 and SNMPv2c management

3. Technical parameters

Parameter specifications

E1 port 16xE1 (75 Ω/120 Ω optional)

Ethernet port 4x10/100BASE-T (RJ45)

Optical interface 2xSTM-1 (SFP, 1310nm)

Power consumption 35W (typical value)

Working temperature -5 ° C~55 ° C

4. Typical application scenarios

Traditional network transformation

Realize the migration of TDM voice services to IP networks

Hybrid access for PBX equipment

Mobile backhaul carrier

2G/3G base station Abis interface transmission

Support IMA (Reverse Reuse) function

Enterprise dedicated line access

Provide n × 64k dedicated line services

Support structured E1 (time slot crossover)

Product imag
