ALCATEL-LUCENT 3HE04164AA Control Processor Module

ALCATEL-LUCENT 3HE04164AA Control Processor Module

Product Details Introduction

ALCATEL-LUCENT 3HE04164AA Control Processor Module Technical Specifications

1. Product Overview

Model: 3HE04164AA

Type: Control Processor

Positioning: Used for system control and management of Alcatel Lucent (Nokia) core network equipment

2. Core functional features

Characteristic Technical Description

Multi core ARM Cortex-A72+x86 coprocessor with processor architecture

Memory configuration 16GB DDR4 ECC (expandable up to 32GB)

Storage System 128GB NVMe SSD+16GB eMMC

Management interface 10G BASE-T out of band management+USB 3.0 maintenance port

Redundant design with 1+1 hot backup (switching time<50ms)

3. Technical parameters

Parameter specifications

Processing performance can manage 2 million routing entries

The protocol supports BGP/OSPF/IS-IS/MPLS/SRv6

Power consumption 65W (typical)/95W (peak)

Working temperature: 0 ° C~45 ° C (commercial grade)

MTBF >150, 000 hours

4. Typical application scenarios

Core router control plane

Main control engine for 7750 SR-12/7950 XRS

Run routing protocol stack and SDN controller

Optical transmission network management

Implementing OTN/SDH control on 1830 PSS platform

Support GMPLS intelligent optical switching

Cloud based network functionality

Carrying VNF instances such as vRouter/vFW

Support containerized application deployment (Kubernetes)

Product imag
