Product Details Introduction

ALCATEL-LUCENT 3HE06336AAAA01 Interface Module - Product Description and Application Analysis

1. Product positioning and basic functions

3HE06336AAAA01 is a high-performance interface module from Alcatel Lucent (now Nokia), mainly used for:

Physical layer interface extension: providing multiple rates of optical/electrical interfaces

Protocol conversion: supports interoperability of different network protocols

Signal conditioning: ensuring signal transmission quality and integrity

2. Typical application scenarios

2.1 Optical Transmission Network

Applied to 1830 PSS optical transmission platform

support:

DWDM wavelength conversion

OTN (G.709) interface

100G/200G high-speed transmission

2.2 IP/MPLS Network

Used for 7750 SR router

Function:

10G/40G/100G Ethernet interface

MPLS label processing

QoS policy execution

2.3 5G Carrier Network

Front transmission (eCPRI) and intermediate transmission interfaces

support:

Low latency transmission (<100 μ s)

Accurate time synchronization (1588v2)

3. Technical specifications (typical)

Parameter specifications

Interface type SFP+/QSFP28/CFP2

Rate of 1G-400G configurable

The protocol supports Ethernet, OTN, Fibre Channel

Transmission distance from short distance (100m) to long distance (80km+)

Power consumption<15W (typical value)

Product imag
