Product Details Introduction

ALCATEL-LUCENT 3AL79092AAAB Port Module - Technical Specifications and Application Guide

1. Product positioning

3AL79092AAAB is a high-density business port module launched by Nokia (formerly Alcatel Lucent), designed specifically for multi service access scenarios, mainly used for:

Business interface expansion of telecom grade equipment

Mixed traffic aggregation and scheduling

Fine tuned control of Quality of Service (QoS)

2. Core specification parameters

Characteristic technical indicators

Physical specifications - Size: 235 × 165 × 25mm (single slot standard)

-Power consumption: typical value of 65W (full load)

Port configuration -48 × 1G SFP or 16 × 10G SFP+(can be split through Breakout cable)

-2 × 40G QSFP+upstream port

Processing capacity - Switching capacity: 320Gbps non blocking

-Packet forwarding rate: 240Mpps

The protocol supports Ethernet/IP/MPLS/VLAN/QinQ/PPPoE

Environmental requirements - Operating temperature: 0 ° C~+45 ° C

-Altitude: ≤ 3000 meters

3. Hardware technology highlights

3.1 Intelligent traffic processing

Level 8 priority queue based on TCAM

Microsecond level traffic shaping (compliant with MEF 22 standard)

Hardware level storm suppression (broadcast/multicast/unknown unicast)

3.2 Flexible Business Adaptation

Port mode configurable (access/aggregation/mirroring)

Support optical and electrical hybrid access (SFP/SFP+hybrid insertion)

MAC address capacity: 64K entries

3.3 Reliability Design

Port level fault isolation

1+1 power input redundancy

Hot swappable compatibility (MTTR<3 minutes)

Product imag
