ALCATEL LUCENT 3DB80581BBAA04 Controller Module

ALCATEL LUCENT 3DB80581BBAA04 Controller Module

Product Details Introduction

ALCATEL-LUCENT 3DB80581BBAA04 is a Controller Module used in operator grade telecommunications equipment. Its numbering structure and purpose indicate that the module may serve Alcatel Lucent's access network, transmission, or multi service platforms, such as ISAM, 1850 TSS, 7750 SR, and perform control, management, and scheduling functions.

1、 Basic product information

Product model: 3DB80581BBAA04

Product Name: Controller Module/Main Control Board

Manufacturer: Alcatel Lucent (now part of Nokia Networks)

Functional positioning: system controller, board scheduling, protocol processing, data forwarding control, status monitoring, etc

2、 Overview of Core Functions

1. System control and resource scheduling

Execute scheduling and management of various business modules within the entire system (such as interface boards, relay modules, etc.).

As the core CPU module, it handles system initialization, startup management, and resource allocation.

2. Network protocol and control logic processing

Run embedded system software that supports communication protocol stacks such as IP/MPLS, VLAN, PPP, SNMP, etc.

Control signaling interaction, business forwarding strategies, and coordinate the working status of multiple physical/logical ports.

3. Management and communication interface support

Provide interfaces for local/remote management, such as RJ-45 management port, serial port, USB, etc. (depending on the platform).

Supports multiple management methods such as CLI, Web, SNMP, Netconf, etc.

4. System health monitoring

Responsible for status collection and alarm control between modules.

Support temperature, voltage, fan, power and other status detection, and output to the monitoring system.

Product imag
