ALCATEL LUCENT 3AL86637BAAF controller module

ALCATEL LUCENT 3AL86637BAAF controller module

Product Details Introduction

ALCATEL-LUCENT 3AL86637BAAF is a Controller Module used in telecommunications equipment. This module model is typical of Alcatel Lucent's optical network access or transmission platform, and has multiple key functions such as processing, scheduling, management, and monitoring.

1、 Basic Information

Product model: 3AL86637BAAF

Product Category: Controller Module/Main Control Board

Manufacturer: Alcatel Lucent (now integrated into Nokia)

Adaptation platform: may be applied to 1850 TSS optical transmission platform or ISAM series access platform, etc

Module positioning: One of the core modules of the system's main control, responsible for overall equipment control and signaling management

2、 Main functions

1. System management and coordination

As the main control logic unit of the whole machine, coordinate the operation status and configuration of all business cards.

Control the on/off sequence, resource allocation, and link coordination of each functional module.

2. Business processing and protocol support

Support the control plane protocols required for device operation, such as MPLS, IP, SDH, OTN, etc.

Participate in forwarding control strategy, traffic scheduling, and QoS strategy execution.

3. Remote and local management interface

Support system configuration, log viewing, and fault handling through Telnet, SNMP, web management, and other methods.

Equipped with a serial port or Ethernet management port for on-site maintenance.

4. Fault detection and alarm management

Real time monitoring of power supply, voltage, temperature, fan status, etc.

Output an alarm signal to the centralized monitoring system when an abnormality occurs.

Product imag
