The GE 193X277ACG02 Signal Level Detector Module is a precision module in the GE 193X series control system. Its main function is to detect whether the input signal has reached the set level threshold and trigger the corresponding control logic or alarm mechanism accordingly. It is widely used in industrial automation, power systems, and drive control systems.

1、 Basic Information

Project Content

Product model 193X277ACG02

Product Name: Signal Level Detector

GE 193X Control Module Series

Function type: Level detection, threshold judgment, alarm triggering

Installation method: Plug in installation (compatible with 193X rack)

2、 Main functions

Function Item Description

Level detection monitors input analog or digital signals in real-time to determine if they exceed the set level threshold

The threshold comparison module is internally equipped with a comparison circuit that compares the input signal with a set reference value

If the input signal is above or below the threshold, an alarm can be triggered through relay output, logic signal, or other means

Control triggering can serve as a conditional triggering module to activate other control function modules in the system

Signal isolation provides electrical isolation to prevent external interference or voltage fluctuations from affecting the core components of the control system

3、 Technical parameters (typical)

Parameter Item Parameter Description

Input signal type: Analog voltage, current signal (0-10V, 4-20mA, etc.)

Detection accuracy ± 0.5% F.S. (depending on version)

The threshold setting range can be adjusted (the specific value is determined by hardware or jumper configuration)

Response time<1ms

Output methods: switch quantity (dry contact), TTL logic signal, relay

Power supply requirement ± 15V DC or+5V DC (depending on the system)

Working temperature -20 ° C~+60 ° C
