193X295AAG01 metering board

193X295AAG01 metering board

Product Details Introduction

193X295AAG01 is a metering board module in the 193X series industrial automation control system launched by General Electric. It is mainly used for measuring and feedback analog signals such as current, voltage, and frequency in industrial electrical systems, and is widely used in control systems such as power generation, transformation, and heavy industry.

2、 Main functions

Accurately measure electrical parameters in the system, such as current, voltage, frequency, etc;

Convert analog signals into system recognizable data;

Provide signal isolation and anti-interference functions;

Support collaborative work with other control modules, such as alarm, display, protection systems, etc.

3、 Technical parameters (typical values)

Input signal: voltage (0-10V, ± 10V), current (4-20mA, ± 20mA)

Accuracy: ± 0.5%

Output format: Analog voltage, current signal or digital signal

Working temperature: -10 ℃ to+60 ℃

Installation method: Plug in card, suitable for 193X control rack

4、 Application Fields

Power plant: used for measuring the electrical quantity of power generation equipment status

Substation: Monitoring parameters such as bus voltage, current, and power

Industrial automation: monitoring equipment operation status and load balancing

Power system: Participate in energy management and scheduling decisions of the system

5、 Product advantages

High precision, fast response, strong anti-interference

Highly compatible with GE control system

Long service life, suitable for harsh industrial environments

Support multiple signal types for input and output

Product imag
