193X456AAG01 power module

193X456AAG01 power module

Product Details Introduction

Introduction to GE 193X456AAG01 Power Module

Model: 193X456AAG01

Type: Power Supply Board

manufacturer: General Electric (GE)

Series: 193X Control System Components

Core functions

Provide stable DC voltage (such as+5V,+15V, -15V, etc.) for various modules within the control system.

It has voltage regulation, filtering, and protection functions to ensure power supply quality.

Possible fault protection mechanisms (such as overcurrent, overvoltage, and over temperature protection) may be equipped.

FEATURES

Installation method: Plug in card structure, installed in GE 193X series control frame.

Main components: transformer, rectifier bridge, filtering capacitor, voltage regulator chip, inductor, fuse.

Input voltage: usually industry standard AC (such as 115V or 230V), depending on the specific model.

Output voltage: multi-channel output, common combinations include:

+5V DC (for digital circuits)

± 15V DC (for analog circuits)

May include auxiliary control voltage (such as 24V DC)

Application scenarios

Power plant automation systems (especially early GE Speedtronic control systems)

Industrial motor control and drive system

The central power supply that supplies power to the control board in a large control cabinet

Standard power accessories for GE 193X series modular control system

Product imag
