Product Details Introduction

PRODUCT INFORMATION

Product model: 193X456AAG03

Product Name: Relay Card

manufacturer: General Electric (GE)

Product Series: 193X Control System Module

PRODUCT FUNCTION

193X456AAG03 is a relay control card in the GE 193X series control system. Its core function is to drive onboard relays through logic control signals, achieving isolation and control between high and low voltage circuits. Mainly used for driving commands, circuit switching, alarm output, etc.

FEATURES

Project Description

The control mode is triggered by the logic board of the control system (such as CPU, driver card) issuing a trigger signal

Output type: Electrical relay contact output (normally open/normally closed)

Multiple channels (usually 4-8 relays)

Electrical isolation relay action provides input and output electrical isolation

Installation structure plug-in card, installed in the standard rack of 193X system

Typical application scenarios

Control high-power electrical contactors, circuit breakers, excitation circuits, etc

As a physical output unit for executing logic

Send out alarm and status feedback signals

Realize remote electrical operation or system linkage control

Maintenance and troubleshooting suggestions

Relay contact adhesion: Use a multimeter to check if the contacts are mechanically stuck

Signal not responding: Check if the control signal input terminal is normal

Electromagnetic coil damage: Check if the resistance of the relay coil is normal (open circuit/short circuit)

Loose connectors: Check if the slots and connecting cables are secure
