Product Details Introduction

Product model: 193X477AAG01

Product Name: Converter Board

manufacturer: General Electric (GE)

Product Series: 193X Industrial Control System Series

FUNCTIONAL OVERVIEW

GE 193X477AAG01 is a converter board used in industrial automation control systems, designed for the conversion and regulation of signal formats, voltage, current, or frequency. It is usually used to connect different subsystems, making them compatible in signal level or data type, and achieving linkage control of the overall system.

Core functions

Conversion between analog and digital signals

Voltage level conversion (e.g. ± 15V to 0-5V conversion)

Frequency adjustment and buffering processing ensure stable signal transmission

Interface bridging function, used for signal matching between different control boards

In motor control systems, it can also be used as an intermediate regulator for PWM or speed signals

Technical parameters (typical)

Parameter description

Supply voltage ± 15V DC (powered by the main system)

Signal type input/output is analog voltage, frequency, or digital TTL signal

Interface type GE 193X series standard slot interface

Working temperature range: 0 ° C to 60 ° C

Structural form card insertion design, onboard multiplexer chip and conditioning circuit

Output protection has basic overvoltage/overcurrent protection mechanisms

Typical application scenarios

Speed signal matching and adjustment in electric motor control system

Signal relay and isolation conversion module

Control signal bridging between multiple module systems

Used as a submodule in the Speedtronic series or EX2000 drive system
