Product Name: System Card

Product model: 193X489AAG01

manufacturer: General Electric (GE)

Product Series: 193X Control System Series

FUNCTIONAL OVERVIEW

GE 193X489AAG01 is a critical system control module used in GE industrial control systems, typically serving as the core board for central coordination and communication, managing data communication, logic signal processing, and control signal scheduling between various submodules.

Core functions

System logic management: As the system control center, it handles and coordinates the logical relationships between various boards

Communication interface bridging: achieving signal synchronization, data sharing, and command transmission

Fault detection and interrupt management: capable of detecting system errors, issuing alarms or protection signals

Power supply allocation and signal distribution: managing signal lines and partial control power distribution

Support self diagnostic function (according to system configuration)

Technical parameters (typical)

Project parameter description

Working voltage ± 15V or 5V DC (system power supply)

Input signal type TTL, analog signal, control instruction

Output interface standard 193X slot output, connected to control board, interface board, etc

Board type: multi-layer PCB, plug-in structure

Working temperature range: 0 ° C to 60 ° C

Multi level filtering and signal buffering protection for anti-interference design

System compatibility is compatible with all motherboards, driver boards, and interface boards of GE 193X for operation

Product imag
