Product Details Introduction

Product Name: Power Supply Board

Product model: 193X526AAG01

manufacturer: General Electric (GE)

Series affiliation: 193X series industrial control system components

PRODUCT FUNCTION

GE 193X526AAG01 is a stable power supply board used in the GE 193X control system. Its main function is to provide the required DC regulated power supply for the modules in the entire control system or subsystem, ensuring the normal and stable operation of the circuit.

Main characteristics

Multi channel output: supports ± 15V+ 5V and other voltage outputs

High stability: Built in voltage regulator chip and filtering circuit, providing low ripple and low noise voltage

Overcurrent protection: equipped with basic current limiting and short-circuit protection functions

Thermal protection design: Some versions have over temperature protection to extend their service life

Plug in structure: easy to replace and maintain, supports standard slots in GE control framework

Technical specification parameters (typical)

Parameter description

Input voltage AC 115V/230V (or provided by system transformer)

Output voltage+5V, ± 15V DC (typical)

The output current varies depending on the load condition, with a maximum of approximately 3~5A (voltage of each circuit)

Stability ≤ ± 1% load adjustment rate

Ripple noise ≤ 50mVp-p (+5V)

Protection functions include overcurrent, short circuit, and overheating protection

Cooling method: natural air cooling or auxiliary air cooling (depending on the system)

PCB form: multi-layer PCB with filtering, power management, and voltage stabilizing devices
