193X526AAG02 DC drive power board

193X526AAG02 DC drive power board power supply board

Product Details Introduction

Product Name: DC Drive Power Supply Board

Product model: 193X526AAG02

manufacturer: General Electric (GE)

Series affiliation: 193X Industrial Control System Series

product description

GE 193X526AAG02 is a board used for DC drive power supply in the 193X control system, mainly providing stable DC power for servo controllers, speed regulation modules, logic control modules, etc. It is usually deployed within DC drive systems, responsible for power conversion, voltage regulation, and distribution to ensure the stable operation of the control system.

Key Function

Provide multiple stable DC output voltages (such as ± 15V,+5V)

Used to support DC driver boards, speed control boards, logic processing boards, etc

Built in voltage regulator, rectifier, and filter

Integrate overcurrent and short-circuit protection circuits to enhance system stability

Plug in card design, convenient for installation, replacement, and system maintenance

Technical specifications and parameters

Parameter Name Typical Value

The input voltage is usually 115V/230V AC (powered by the system bus)

Output voltage+5V, ± 15V DC (common specifications)

The output current capacity depends on the number of circuits, typically ranging from 2 to 5A

Load adjustment rate ≤± 1% (when switching between full load and light load)

Ripple noise ≤ 50mVp-p (5V output)

Cooling method: natural air cooling/external fan assistance

Structural form: Plug in multi-layer PCB with gold finger interface

Protection functions include overvoltage, overcurrent, overtemperature, and short-circuit protection

Product imag
