193X543ADG01 relay module

193X543ADG01 relay module

Product Details Introduction

GE 193X543ADG01 is a relay function module in General Electric's 193X series industrial control systems. This module is designed to implement logic control, state switching, circuit protection, and other functions in control systems. It is commonly used in GE's DC or AC drive systems and large automation control equipment.

The relay module is one of the key execution components in the system, which can be used to control various on-site operations such as motor start stop, load switching, alarm linkage, etc.

Technical parameters and functional characteristics

Product model: 193X543ADG01

Module type: Relay Board Module

Circuit structure: composed of multiple electromagnetic relays, driving transistors, protective diodes, capacitors, resistors, etc

Control logic: Receive trigger signals from the main control board to control the on/off status of relays

Number of relay channels: usually 4-8 channels (depending on the version)

Relay type: Electromagnetic dry contact with normally open (NO)/normally closed (NC) terminals

Drive voltage:+24V DC or ± 15V DC provided by the system (depending on the system configuration)

Response time: Typical relay pull in/release time is 10-20ms

Load capacity: Each relay usually supports switching between 1~2A (AC or DC load)

Working temperature range: -20 ℃~+70 ℃

Onboard protection: equipped with a freewheeling diode to protect the relay coil and prevent device damage caused by induced voltage

Interface form: Connect the system backplane through a gold finger slot, or use screw terminals for external wiring

function

Control logic execution: Receive system logic signals to perform operations such as starting, stopping, and fault cutting of equipment

Status indication: Some modules are equipped with indicator lights to display the relay action status

Safe shutdown: used for power disconnection control in situations such as overload, malfunction, emergency stop, etc

Multi channel control: can independently control multiple sets of circuits to achieve multiple logic output functions

application area

GE Mark Series Drive Control System

Industrial Motor Control Center (MCC)

Inverter and rectifier control system

Power switching/alarm system in automated production line

Control systems for heavy industries such as petrochemicals, metallurgy, power plants, cement, and papermaking

Product imag
