193X543ADG02 relay card

193X543ADG02 relay card

Product Details Introduction

GE 193X543ADG02 is a multi-channel relay output card in the General Electric 193X series, mainly used in industrial automation systems and drive control systems to complete tasks such as circuit switching, signal linkage, alarm triggering, and execution control. This module drives multiple electromagnetic relays by receiving instructions from the main control unit, achieving on-off actions under different control logics.

This module is widely used in GE's DC/AC drive systems and early Mark series control systems, suitable for industrial equipment start stop, fault protection, sequence control and other scenarios.

Technical parameters and functional characteristics

Product model: 193X543ADG02

Product Name: Relay Card

Function type: Circuit switch control, status switching, alarm output, etc

Number of channels: generally includes 4-8 independently controlled relays (depending on the actual version)

Contact type: normally open (NO)/normally closed (NC) dry contact output

Coil driving voltage: 24V DC or ± 15V DC (powered by the system)

Contact rated load: approximately 1~2A @ 250V AC or 30V DC (depending on relay specifications)

Response time: Typical 10-20ms

Control mode: The onboard logic interface is controlled by the motherboard and triggers actions automatically or through a program

Interface form: Gold finger connector (used for inserting into GE control frame backplane)

Onboard protection circuit: equipped with freewheeling diode, anti reverse protection, voltage clamp and other circuits

Display function: Some versions come with LED indicator lights that reflect the current status of each relay

Working temperature range: -20 ° C~+70 ° C

Size: Standard 193X series control board size, hot swappable or module replaceable

Functional application

Implement logical switch actions in the control system

Control the start stop of motors, fans, pumps, or other executing devices

System alarm linkage triggering (sound and light alarm, power-off protection)

Equipment operation status switching (working/standby/fault)

Isolation contact output for safety control systems

Product imag
