193X565ABG01 PC board

193X565ABG01 PC board

Product Details Introduction

GE 193X565ABG01 is a signal processing and control logic circuit board (PC board) in the General Electric 193X series control system. This module is used in GE automation control systems (such as early Mark series or drive control systems) to achieve key functions such as signal acquisition, logic judgment, intermediate relay control, and status processing. The 193X series is widely used in automation control systems such as power, metallurgy, and petrochemicals due to its modular design, standardized interfaces, and industrial grade reliability.

Technical parameters and functional characteristics

Product model: 193X565ABG01

Product Name: PC Board/Printed Circuit Board

Function type: Signal logic processing and control output

Main functions: signal acquisition, data transmission, intermediate control, relay logic switching, etc

Interface form: Gold finger PCB slot connection, compatible with GE 193X backplane system

Power requirement: ± 15V DC/+24V DC (powered by the system)

Onboard components: including logic chips, resistors, capacitors, transistors, potentiometers, small relays, etc

Logic level standard: TTL or CMOS (depending on the chip on the board)

Onboard functional modules: may include voltage detection, comparator, driver, buffer, etc

Working temperature range: -20 ° C~+70 ° C

Dimensions: Standard GE 193X series dimensions for easy modular replacement

Installation method: Horizontal plug-in installation, fixed in the system backplane

function

As a signal relay and processing unit between the main control system and the execution module

Implement functions such as logical judgment, command conversion, and state maintenance

Receive system command signals and generate relay or control level signals for output

Preprocess the input signal by filtering, shaping, amplifying, isolating, etc

Collaborate with other modules in the 193X series to complete the entire automatic control logic chain

Application scenarios

Early drive and process control systems such as GE Mark II/IV

Large industrial motor control and excitation system

Automation control system for thermal power plants

Petrochemical plant DCS/PLC control module

High demand automation control site for metallurgy, papermaking, cement and other industries

Product imag
