193X637ACG04 Statistical Board

193X565ABG01 PC board

Product Details Introduction

GE 193X637ACG04 is a statistical control module (Statistics Board) in the General Electric 193X series, mainly used for operational data statistics and processing functions in GE control systems. This board is typically used for monitoring, recording, and processing status change data in industrial processes, such as running time counting, fault counting, startup frequency statistics, etc.

As one of the functional components of the 193X series control system, this module adopts a modular plug-in structure design, which can exchange data and connect signal logic with the main control system.

Technical parameters and functional characteristics

Product model: 193X637ACG04

Product Name: Statistical Board

Function type: Running status counting, data statistics, and output

Typical application functions:

Accumulated running time statistics

Start/stop count

Record of the number of occurrences of faults

External signal pulse counting and triggering logic

Input signal type: pulse signal/digital signal (TTL or 24V logic)

Output signal types: counter output, comparison signal, status flag bit, etc

Counting range: usually supports a counting depth of 16 bits or higher (depending on the chip model)

Clock control: onboard or external clock synchronization control

Onboard components: logic ICs (such as counters, latches), transistors, capacitors, resistors, LED indicators, etc

Working voltage:+ 5V/± 15V DC (powered by the system)

Status indication: equipped with status lights (LED) to display statistics or trigger status

Connection method: Gold finger slot interface, suitable for GE control system backplane

Working temperature range:- 20°C ~ +70°C

Size standard: Complies with GE 193X series control system module specifications

function

Real time statistics and recording of various operating states in the system

Provide statistical output of the number or frequency of start/stop signals

As a data support module for the upper computer or monitoring system

After triggering a certain counting threshold, output control signals for interlocking protection or maintenance reminders

Can be linked with the alarm module to achieve periodic maintenance reminder function
